MAGNETIC TEMPLATE 120x120

Reference: PLANTILLA_MAG120x120

Condition: New product

The 120x120 MAGNETIC TEMPLATE makes it possible to make bends (with the possibility of using patterns) that would be very difficult with the traditional back stop.

Great grip, by means of two very powerful magnets (33 Kg of force)

INOX sheet dimensions; 120x120x8 m/m

It is supplied with 4 M6x10 m/m Allen screws

Weight: 2 Kg

At the bottom of this page you can DOWNLOAD the plane in PDF-DWG.

More details

72 UNIT AVAILABLE STOCK UNITS AVAILABLE STOCK

Rating

Read users comments below (1)
Write a review

Send to a friend
Send to a friend

MAGNETIC TEMPLATE 120x120
The 120x120 MAGNETIC TEMPLATE makes it possible to make bends (with the possibility of using patterns) that would be very difficult with the traditional back stop.
Great grip, by means of two very powerful magnets (33 Kg of force)
INOX sheet dimensions; 120x120x8 m/m
It is supplied with 4 M6x10 m/m Allen screws
Weight: 2 Kg
At the bottom of this page you can DOWNLOAD the plane in PDF-DWG.
Recipient :
Name of your friend ^* :
E-mail address of your friend ^* :
^* Required fields
or Cancel
Print

More info

See it on YOUTUBE

The 120x120 MAGNETIC TEMPLATE is designed to make the operator’s work easier, making it possible to hold patterns or negatives of the parts to be able to bend them with complete guarantees. Ideal for small parts and in which, due to the geometry of the part, it is difficult to use the traditional back stops.

The adaptation is very simple and fast as a result of its two powerful magnets (33 Kg of force). The low price of this 120x120 MAGNETIC TEMPLATE will be quickly recovered, greatly reducing preparation time in the press brake.

Reviews

Grade

Adrià 05/31/2023

Compra 2 unidades

Hemos comprado dos unidades con el objetivo de utilizarla para hacer escuadra con las piezas pequeñas. Ahora la utilizamos tambien para hacer piezas de geometrias díficiles lo que nos permite fabricar con menor tiempo. 100% recomendable
