Promecam-European DIES

PROMECAM-EUROPEAN MRA DIES FOR PRESS BRAKE

Promecam-European DIES There are 4 products.

Showing 1 - 4 of 4 items
  • Quick view
    $1,293.75 IN STOCK

    Recommended thickness from 0,5 to 1,5 m/m (possible 2 m/m Fe) In 1,5 m/m minimum interior flange of 4,5 m/m Minimum angle at 35º Equivalence with V=8 m/m Maximum tonange 100 Ton/mt Sectioning of 450 m/m; 20 - 25 - 30 - 35 - 40 - 100 y 200 m/m L=500 m/m 7Kg At the bottom of this page you can DOWNLOAD the plane in PDF with 1:1 scale. Measures in milimeters...

    $1,293.75
    IN STOCK
  • Quick view
    $1,374.25 IN STOCK

    Recommended thickness from 2 to 3,2 m/m (possible 4 m/m Fe) In 2 m/m minimum interior flange of 6 m/m. In 3 m/m minimum interior flange of 7 m/m.  Minimum angle at 60º Equivalence with V=15 m/m Maximum tonange 150 Ton/mt Sectioning of 450 m/m; 20 - 25 - 30 - 35 - 40 - 100 y 200 m/m L=500 m/m 8Kg At the bottom of this page you can DOWNLOAD the plane in PDF...

    $1,374.25
    IN STOCK
  • Quick view
    $2,409.25 IN STOCK

    Recommended thickness from 4 to 6 m/m (possible 8 m/m Fe) In 4 and 6 m/m minimum interior flange of 18 m/m Minimum angle at 50º Equivalence with V=35 m/m Maximum tonange 250 Ton/mt Sectioning of 455 m/m; 45 - 50 - 60 - 100 y 200 m/m L=500 m/m 29Kg At the bottom of this page you can DOWNLOAD the plane in PDF with 1:1 scale.

    $2,409.25
    IN STOCK
  • Quick view
    $2,978.50 DELIVERY 5 WEEKS AFTER ORDER

    Recommended thickness from 6 to 12 m/m (possible 16 m/m Fe) In 6 and 8 m/m minimum interior flange of 56 m/m Minimum angle at 75º Equivalence with V=85 m/m Maximum tonange 300 Ton/mt L=500 m/m 60Kg At the bottom of this page you can DOWNLOAD the plane in PDF. Measures in milimeters (1 milimeter = 0,0393701 inches)

    $2,978.50
    DELIVERY 5 WEEKS AFTER ORDER
Showing 1 - 4 of 4 items
