MRA DIES (WING BEND)

Dies MRA (WING BEND)

No marks on the metal sheets.

The holes near the folding area are not deformed.

Realization of very small tabs.

MRA DIES (WING BEND) There are 13 products.

Subcategories

per page
Showing 1 - 12 of 13 items
  • $1,138.50 $1,423.13 -20% IN STOCK

    Recommended thickness from 0,5 to 1,5 m/m (possible 2 m/m Fe) In 1,5 m/m minimum interior flange of 4,5 m/m Minimum angle at 35º Equivalence with V=8 m/m Maximum tonange 100 Ton/mt Sectioning of 450 m/m; 20 - 25 - 30 - 35 - 40 - 100 y 200 m/m L=500 m/m 7Kg At the bottom of this page you can DOWNLOAD the plane in PDF with 1:1 scale. Measures in milimeters...

    $1,138.50 $1,423.13 -20%
    Reduced price!
    IN STOCK
  • $1,138.50 $1,423.13 -20% IN STOCK

    Recommended thickness from 0,5 to 1,5 m/m (possible 2 m/m Fe) In 1,5 m/m minimum interior flange of 4,5 m/m Minimum angle at 35º Equivalence with V=8 m/m Maximum tonange 100 Ton/mt Sectioning of 450 m/m; 20 - 25 - 30 - 35 - 40 - 100 y 200 m/m L=500 m/m 7Kg At the bottom of this page you can DOWNLOAD the plane in PDF with 1:1 scale. Measures in milimeters...

    $1,138.50 $1,423.13 -20%
    Reduced price!
    IN STOCK
  • $1,052.48 $1,315.60 -20% DELIVERY 5 WEEKS AFTER ORDER

    Recommended thickness from 0,5 to 1,5 m/m (possible 2 m/m Fe) In 1,5 m/m minimum interior flange of 4,5 m/m Minimum angle at 35º Equivalence with V=8 m/m Maximum tonange 100 Ton/mt Sectioning of 450 m/m; 20 - 25 - 30 - 35 - 40 - 100 y 200 m/m L=500 m/m 7Kg At the bottom of this page you can DOWNLOAD the plane in PDF with 1:1 scale. Measures in milimeters...

    $1,052.48 $1,315.60 -20%
    Reduced price!
    DELIVERY 5 WEEKS AFTER ORDER
  • $1,209.34 $1,511.68 -20% IN STOCK

    Recommended thickness from 2 to 3,2 m/m (possible 4 m/m Fe) In 2 m/m minimum interior flange of 6 m/m. In 3 m/m minimum interior flange of 7 m/m.  Minimum angle at 60º Equivalence with V=15 m/m Maximum tonange 150 Ton/mt Sectioning of 450 m/m; 20 - 25 - 30 - 35 - 40 - 100 y 200 m/m L=500 m/m 8Kg At the bottom of this page you can DOWNLOAD the plane in PDF...

    $1,209.34 $1,511.68 -20%
    Reduced price!
    IN STOCK
  • $1,275.12 $1,593.90 -20% IN STOCK

    Recommended thickness from 2 to 3,2 m/m (possible 4 m/m Fe) In 2 m/m minimum interior flange of 6 m/m. In 3 m/m minimum interior flange of 7 m/m.  Minimum angle at 60º Equivalence with V=15 m/m Maximum tonange 150 Ton/mt Sectioning of 450 m/m; 20 - 25 - 30 - 35 - 40 - 100 y 200 m/m L=500 m/m 12,5Kg At the bottom of this page you can DOWNLOAD the plane in...

    $1,275.12 $1,593.90 -20%
    Reduced price!
    IN STOCK
  • $1,224.52 $1,530.65 -20% DELIVERY 5 WEEKS AFTER ORDER

    Recommended thickness from 2 to 3,2 m/m (possible 4 m/m Fe) In 2 m/m minimum interior flange of 6 m/m. In 3 m/m minimum interior flange of 7 m/m.  Minimum angle at 60º Equivalence with V=15 m/m Maximum tonange 150 Ton/mt Sectioning of 450 m/m; 20 - 25 - 30 - 35 - 40 - 100 y 200 m/m L=500 m/m 8Kg At the bottom of this page you can DOWNLOAD the plane in PDF...

    $1,224.52 $1,530.65 -20%
    Reduced price!
    DELIVERY 5 WEEKS AFTER ORDER
  • $2,120.14 $2,650.18 -20% IN STOCK

    Recommended thickness from 4 to 6 m/m (possible 8 m/m Fe) In 4 and 6 m/m minimum interior flange of 18 m/m Minimum angle at 50º Equivalence with V=35 m/m Maximum tonange 250 Ton/mt Sectioning of 455 m/m; 45 - 50 - 60 - 100 y 200 m/m L=500 m/m 29Kg At the bottom of this page you can DOWNLOAD the plane in PDF with 1:1 scale.

    $2,120.14 $2,650.18 -20%
    Reduced price!
    IN STOCK
  • $2,120.14 $2,650.18 -20% IN STOCK

    Recommended thickness from 4 to 6 m/m (possible 8 m/m Fe) In 4 and 6 m/m minimum interior flange of 18 m/m Minimum angle at 50º Equivalence with V=35 m/m Maximum tonange 250 Ton/mt Sectioning of 455 m/m; 45 - 50 - 60 - 100 y 200 m/m L=500 m/m 29Kg At the bottom of this page you can DOWNLOAD the plane in PDF with 1:1 scale.

    $2,120.14 $2,650.18 -20%
    Reduced price!
    IN STOCK
  • $1,988.58 $2,485.73 -20% DELIVERY 5 WEEKS AFTER ORDER

    Recommended thickness from 4 to 6 m/m (possible 8 m/m Fe) In 4 and 6 m/m minimum interior flange of 18 m/m Minimum angle at 50º Equivalence with V=35 m/m Maximum tonange 250 Ton/mt Sectioning of 455 m/m; 45 - 50 - 60 - 100 y 200 m/m L=500 m/m 29Kg At the bottom of this page you can DOWNLOAD the plane in PDF with 1:1 scale.

    $1,988.58 $2,485.73 -20%
    Reduced price!
    DELIVERY 5 WEEKS AFTER ORDER
  • $2,621.08 $3,276.35 -20% DELIVERY 5 WEEKS AFTER ORDER

    Recommended thickness from 6 to 12 m/m (possible 16 m/m Fe) In 6 and 8 m/m minimum interior flange of 56 m/m Minimum angle at 75º Equivalence with V=85 m/m Maximum tonange 300 Ton/mt L=500 m/m 60Kg At the bottom of this page you can DOWNLOAD the plane in PDF. Measures in milimeters (1 milimeter = 0,0393701 inches)

    $2,621.08 $3,276.35 -20%
    Reduced price!
    DELIVERY 5 WEEKS AFTER ORDER
  • $2,762.76 $3,453.45 -20% DELIVERY 5 WEEKS AFTER ORDER

    Recommended thickness from 6 to 12 m/m (possible 16 m/m Fe) In 6 and 8 m/m minimum interior flange of 56 m/m Minimum angle at 75º Equivalence with V=85 m/m Maximum tonange 300 Ton/mt L=500 m/m 60Kg At the bottom of this page you can DOWNLOAD the plane in PDF. Measures in milimeters (1 milimeter = 0,0393701 inches)

    $2,762.76 $3,453.45 -20%
    Reduced price!
    DELIVERY 5 WEEKS AFTER ORDER
  • $2,013.88 $2,517.35 -20% DELIVERY 5 WEEKS AFTER ORDER
    New

    Recommended thickness from 2 to 5 m/m (possible 6 m/m Fe) In 4 m/m minimum interior flange of 14 m/m In 6 m/m minimum interior flange of 12 m/m Minimum angle at 50º Equivalence with V=25 m/m Maximum tonange 250 Ton/mt Sectioning of 470 m/m; 35 - 40 - 45 - 50 - 100 y 200 m/m L=500 m/m 22Kg At the bottom of this page you can DOWNLOAD the plane in PDF with...

    $2,013.88 $2,517.35 -20%
    Reduced price!
    DELIVERY 5 WEEKS AFTER ORDER
Showing 1 - 12 of 13 items
